British Standard BS75A Steel Rail: Premium BS75a Steel Rail for Reliable Railway Infrastructure
BS75a Steel Rail provided by YongYang is a cornerstone in modern railway systems, designed and manufactured according to stringent British Standard BS11 specifications. This advanced rail product, known as the British Standard BS75A Steel Rail, delivers exceptional performance and durability for diverse rail applications.
The BS75a Steel Rail is engineered to meet the demands of mainline railways, industrial tracks, and light to medium-duty freight systems. Manufactured using high-quality 700 or 900A grade steel, this rail offers a robust profile with a weight of 75 pounds per yard (approximately 38 kilograms per meter). Its standard lengths, ranging from 5 to 25 meters or custom sizes per customer requirements, ensure versatile installation across various railway projects.
Specifications
YongYang British Standard BS75A Steel Rail features precise dimensions, including a height of 165 millimeters, a base width of 120 millimeters, and a head width of 76 millimeters. With a web thickness of 18 millimeters and a flange thickness of 21 millimeters, the BS75a Steel Rail is optimized for stability, strength, and longevity, adhering to the rigorous BS11 standard.
| R350HT | Mechanical Property | Chemical Composition | |||||||||
| Tensile strength | Elongation | Hardness | C | Si | Mn | S | P | H ppm | O ppm | ||
| MPa | kg/mm² | min | HB | ≤ | ≤ | ≤ | ≤ | ||||
| ≥1175 | 9% | 350-390 | 0.72-0.80 | 0.15-0.58 | 0.70-1.20 | 0.025 | 0.02 | 2.5 | |||
| R260 / U71Mn /900A | Mechanical Property | Chemical Composition | |||||||||
| Tensile strength | Elongation | Hardness | C | Si | Mn | S | P | H ppm | O ppm | ||
| MPa | kg/mm² | min | HB | ≤ | ≤ | ≤ | ≤ | ||||
| ≥880 | 10% | 260-300 | 0.62-0.80 | 0.15-0.58 | 0.70-1.20 | 0.025 | 0.025 | 2.5 | 20 | ||
Key Advantages of YongYang British Standard BS75A Steel Rail
One of the main advantages of YongYang BS75A Steel Rail is its versatility. Its high load-bearing capacity and continuous welded structure minimize the risk of rail breaks or derailments, making it a safe and cost-effective choice for both urban and industrial applications. Other benefits include:
-
Durability: Manufactured from high-quality steel and rigorously tested for tensile strength, impact resistance, and fatigue performance.
-
Ease of Installation: Standardized dimensions and fittings such as fishplates, bolts, and clips allow for various installation methods including direct fixing, clamping, or welding.
-
Maintenance Efficiency: The BS75a Steel Rail is designed for straightforward maintenance and long-term reliability, reducing overall lifecycle costs.
Applications
The BS75a Steel Rail is widely utilized in railway infrastructure projects across the United Kingdom and other regions adhering to British standards. Common applications include:
-
Mainline and urban railways
-
Industrial rail tracks and factory workshops
-
Mine roadways and specialized railway lines
-
Cranes and heavy-duty freight transportation
Installation and Technical Support
YongYang Rail provides comprehensive technical support for the BS75a Steel Rail, offering services such as precise rail processing (e.g., 45-degree mitre cuts, welding, milling, and special profile processing). Our expert engineers work closely with clients to design and implement tailored rail solutions that optimize performance and minimize lifecycle costs. The ease of installation is further enhanced by our supply of compatible rail parts like fishplates, rail clips, bolts, and nuts.
The ideal solution for modern rail infrastructure projects, British Standard BS75A rail combines strength, versatility and safety in the highly reliable BS75a rail. With strict manufacturing standards, advanced technical support and proven performance, YongYang's BS75a rails meet and exceed industry expectations. Trust YongYang Rail to deliver long-lasting performance and optimal safety for your railroad network.
