Hebei Yongyang Special Steel Group Co., Ltd. offers high-quality 24kg Light Steel Rail, adhering to GB standards and designed for optimal performance in mining and railway applications. With over 30 years of experience, we specialize in manufacturing and supplying a wide range of rails, including light rail, heavy rail, and crane rail, along with associated accessories and services.
Key Features of YongYang 24kg Light Steel Rail
1. Premium GB Standard Design
The 24kg Light Steel Rail meets GB standards, ensuring reliability and durability. It provides continuous, smooth, and minimal rolling surfaces for locomotive wheels, enhancing transportation efficiency.
2. Load-Bearing Functionality
Designed to bear heavy loads and guide locomotive wheels, this rail type is essential for maintaining stability in railway transport systems. The 24kg rail works seamlessly with track wheels to support weight and alter cart direction as needed.
3. Versatility in Application
The 24kg Light Steel Rail is suitable for a variety of industries, including:
-
Mining: Used for temporary transportation lines and light locomotive tracks in mining areas.
-
Forestry: Supports the efficient movement of goods in forested regions.
-
Construction: Ideal for laying light rail lines in construction sites.
-
Industrial Applications: Perfect for factories requiring temporary or light locomotive lines.
Product Specification
Size: 24kg/m
Length: 5-12m or other length according to customers’ requirement
Material: Q235B, 55Q
Standard: GB/T11264-2012
| Q235 | Mechanical property | Chemical composition(%) | |||||||||
| Yield strength | Tensile strength | Elongation | Hardness | C | Si | Mn | S | P | |||
| MPa
≥ |
kg/mm²
≥ |
MPa | kg/mm² | min | HB | ≤ | ≤ | ≤ | |||
| 235 | 24 | 375-460 | 38-47 | 26% | 0.12-0.22 | 0.35 | 0.30-0.70 | 0.045 | 0.045 | ||
……………………………………………………………………………………………………………………………………………………………………………………………
| 55Q | Mechanical property | Chemical composition(%) | |||||||||
| Yield strength | Tensile strength | Elongation | Hardness | C | Si | Mn | S | P | |||
| MPa
≥ |
kg/mm²
≥ |
MPa
≥ |
kg/mm²
≥ |
min | HBW
≥ |
≤ | ≤ | ||||
| 685 | 69 | 197 | 0.50-0.60 | 0.15-0.35 | 0.60-0.90 | 0.040 | 0.040 | ||||
Light Rail
Standard: GB/T 11264-2012
| Size
* |
Rail height(mm)
A |
Bottom Width(mm)
B |
Head Width(mm)
C |
Web Thickness(mm)
t |
Weight(kg/m)
* |
| 8kg | 65 | 54 | 25 | 7 | 8.42 |
| 9kg | 63.5 | 63.5 | 32.1 | 5.9 | 8.94 |
| 12kg | 69.85 | 69.85 | 38.1 | 7.54 | 12.2 |
| 15kg | 79.37 | 79.37 | 42.86 | 8.33 | 15.2 |
| 18kg | 90 | 80 | 40 | 10 | 18.06 |
| 22kg | 93.66 | 93.66 | 50.8 | 10.72 | 22.3 |
| 24kg | 107 | 92 | 51 | 10.9 | 24.46 |
| 30kg | 107.95 | 107.95 | 60.33 | 12.3 | 30.1 |
Services and Customization Options
1. Comprehensive Technical Support
Our expert team provides tailored advice to optimize rail selections, helping customers minimize life-cycle costs.
2. Rail Accessories and Processing
Yongyang Rail supplies a range of rail parts, including:
-
Fish plates, rail clips, bolts, and nuts.
-
Specialized processing services, such as 45-degree mitre cuts, welding, milling, and custom profile designs.
3. End-to-End Solutions
Our engineers can assist in designing railroad lines, including mining railroad systems and crane-moving tracks, ensuring your project's success.
The Function of YongYang Steel Rail in Railway Tracks
Steel rail, also referred to as rail track or steel track, serves as the primary component of railway systems. Its primary functions include:
-
Wheel Guidance: Guides locomotive wheels for smooth transport.
-
Pressure Bearing: Bears the significant weight of locomotives and cargo.
-
Stability Maintenance: Maintains the overall stability of railway transport.
In electrified railways or automatic block sections, steel rails also function as orbital circuits, further increasing their utility.
The 24kg Light Steel Rail from China's Hebei Yongyang Special Steel Group is an industry-leading product designed for diverse applications, including mining, forestry, and construction. Offering durability, functionality, and customizable solutions, our GB Standard rails ensure maximum efficiency and long-lasting performance. If you're looking for reliable 24kg light steel rail, contact YongYang for professional advice and support tailored to your project needs. Let us help you build durable and efficient rail systems today!
……………………………………………………………………………………………………………………………………………………………………………………………
In order to better serve the different needs of customers, our technical team is available to provide advice and support, helping every customer to optimize their rail selections to minimize life cycle costs. We supply suitable rail parts, like fish plates, rail clips, bolts and nuts. We supply rail processing, like 45 degree mitre cut, welding process, milling process, special profile processing, etc. Our engineer help customer to design railroad line according to requirements, and build mining railroad line and crane moving line. The technical support provided by YONGYANG Rail can ensure that every rail we deliver provides optimum performance throughout its service life.
